Induction Based Gold Melting Machine 20 kg. With Tilting Unit

Induction Based Gold Melting Machine 20 kg. With Tilting Unit

300000.00 - 1000000.00 INR/Piece

Get a Price/Quote

Product Details:

Product Type induction Based Melting
General Use Gold/Silver Melting
Material Other
Weight (kg) 283 Kilograms (kg)
Computerized No
Automatic No
Control System Frequency Speed Control
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Induction Based Gold Melting Machine 20 kg. With Tilting Unit Price And Quantity

Minimum Order Quantity 1 Piece
Price Range 300000.00 - 1000000.00 INR/Piece

Induction Based Gold Melting Machine 20 kg. With Tilting Unit Product Specifications

Material Other
Working Temperature 1150 Celsius (oC)
Power Supply 3 Phase 440 Volts A/C
Color Gray
Weight (kg) 283 Kilograms (kg)
Control System Frequency Speed Control
Wire Dimension 3 Core
Cooling Mode Water Cooling
General Use Gold/Silver Melting
Product Type induction Based Melting
Computerized No
Feature Simple Control Polishing Tumblers High Performance ECO Friendly High Efficiency Lower Energy Consumption Low Noise
Warranty 1 Year
Automatic No
Dimension (L*W*H) 860.00 x 610.00 x 1130.00 Millimeter (mm)
Metals Type Othger

Induction Based Gold Melting Machine 20 kg. With Tilting Unit Trade Information

FOB Port Kandla Port
Payment Terms Cash Advance (CA) Cash in Advance (CID) Cheque
Supply Ability 10 Piece Per Week
Delivery Time 1 Week
Sample Policy Contact us for information regarding our sample policy
Main Domestic Market All India

Product Description

Induction Based Gold Melting 20 Kg With Tilting Unit

Useful for:

High volume jewellery manufacturers, Alloy manufacturers, Chain manufacturers, Metal processing refineries, Useful for coins and bar manufacturers.

Product Features:

Perfect Homogeneous mixing due to auto stirring effect for increased productivity and perfect alloying.
Economical, Efficient and Simple in Operation.
Energy saving flameless device and also 80% income tax depreciable.
Does not affect room temperature.
Heat and power loss reduced.
Works on 3 Phase connection.
Provides controlled pouring of metal due to manual tilting unit.
Metal can be added easily during the melting process for continuous melting operation.

Technical Specifications:

Technology: IGBT Based.
Power Supply & Voltage: 3 Phase 440 Volts A/C
Absorbed Power: 16 KW/H.
Capacity of Crucible: 20 Kgs. Gold.
Maximum Temperature & Type: 1200⁰Degrees, "K" Type.
Melting Time: 12 to 15 Minutes.
Cooling Water Temperature: 35⁰Degrees Max.
Machine Weight: Approx 79 Kgs.
Chiller Weight: Approx 130.5 Kgs.
Tilting Weight: Approx 60 kgs.
Machine Size (LxWxH): Approx 80 x 60 x 113 (cms).
Chiller Size (LxWxH): Approx 84 x 59 x 105 (cms).
Tilting Size (LxWxH): Approx 84 x 62 x 92 (cms).
