Induction Based Melting With Tilting Unit

300000.00 - 500000.00 INR/Unit

Product Details:

  • General Use Gold/Silver Melting
  • Material Other
  • Capacity 15
  • Computerized No
  • Automatic Yes
  • Control System Frequency Speed Control
  • Cooling Mode Water Cooling
  • Click to view more
X

Price And Quantity

  • 300000.00 - 500000.00 INR/Unit
  • 1 Unit

Product Specifications

  • Other
  • No
  • Gold/Silver Melting
  • Frequency Speed Control
  • Yes
  • 15
  • 1150 Celsius (oC)
  • 32 Ampere (amp)
  • Water Cooling

Trade Information

  • 10 Unit Per Week
  • 1 Week
  • All India

Product Description

Induction Based Aluminium Melting Furnace 15 kg . With Tilting Unit

Useful for:


High volume Industrial manufacturers, Scrap Melting , Alloy Makers etc.

Product Features:


  • Perfect Homogeneous mixing due to auto stirring effect for increased productivity and perfect alloying.
  • Economical, Efficient and Simple in Operation.
  • Energy saving flameless device and also 80% income tax depreciable.
  • Does not affect room temperature.
  • Heat and power loss reduced.
  • Works on 3 Phase connection.
  • Provides controlled pouring of metal due to manual tilting unit.
  • Metal can be added easily during the melting process for continuous melting operation.

Technical Specifications:

  • Technology: IGBT Based.
  • Power Supply & Voltage: 3 Phase 440 Volts A/C
  • Absorbed Power: 32 KW/H.
  • Capacity of Crucible: 15 Kg Aluminium.
  • Maximum Temperature & Type: 12000 Degrees, "K" Type.
  • Melting Time: 12 to 15 Minutes.
  • Cooling Water Temperature: 350 Degrees Max.
  • Machine Weight: Approx 79 Kgs.
  • Chiller Weight: Approx 130.5 Kgs.
  • Tilting Weight: Approx 60 kgs.
  • Machine Size (LxWxH): Approx 80 x 60 x 113 (cms).
  • Chiller Size (LxWxH): Approx 84 x 59 x 105 (cms).
  • Tilting Size (LxWxH): Approx 84 x 62 x 92 (cms).
